LiFePo4 life expectancy is approximately 5-7 years with a High Cycle Life > 2000 times.
Built-in Battery Management System
Traditional Lead Acid & GEL batteries should only be run to 50% depth of discharge,
LiFePo4 lithium batteries can handle deep discharges of 80% or more.
Longer life span, no maintenance, extremely safe, lightweight, improved discharge, and faster charge efficiency.
Suitable SLA Replacement – Gate Motor, Fence Energizer, Alarm System & Garage door
Note: many UPS devices have compatibility issues with LiFePo4 batteries. Some are unable to meet the required BMS Charging Voltage of 14.6V. We do not recommend using this product as a suitable replacement without doing proper research and consulting your technician.
Technical Specifications:
- Rated Capacity 7Ah
- Nominal Voltage 8V
- BMS Charging Voltage 6V
- Rated operational current 7A
- Energy 6Wh
- Terminal F1 (South African Standard)
- Dimensions 151mm (L) x 65mm (W) x 95mm (H)
- BMS Specification
- Cell overcharge detection voltage 75V±50mV
- Cell overcharge recovery voltage 55V±50mV
- Cell over-discharge detection voltage 20V±50mV
- Cell over-discharge recovery voltage 7V±100mV
- Over current detection ≤50mΩ
- Battery Management System are incorporated to protect battery from OVER CHARGING, OVER DISCHARGING, SHORT CIRCUIT
- Series and parallel connections are not recommended.
Cautions:
Do not submerge the battery in water.
Do not expose the battery to an open flame or extreme temperatures.
Do not crush or disassemble.
Do not short circuit.
Store at 50% capacity, recharge every 3 months if not in use.
